• Channel width comparison for 2D Two-Phase flows

    This test shows the deceleration of a rising bubble due to the distance between lateral walls. As can be seen, the larger is the channel width the faster is the rising bubble. The right hand side figure does not even arrive at the middle of the channel length for the exactly same parameters and time step to all simulat

    Duration: 26s
  • Rising bubble in quiescent liquid using arbitrary quadrilateral mesh

    Numerical simulation using the Finite Element method for 2D Two-Phase flows with deformable interface in arbitrary quadrilateral mesh.

    Non-dimensional parameters of the simulation:

    Re = 10 # Reynolds We = 10 # Weber Fr = 1.0 # Froude dynamic viscosity ratio = 2 density ratio = 100

    Duration: 15s
  • Efficient Laplacian Smoothing on Quadrilateral Mesh

    This animations show the effect of the Laplacian Smoothing operation on quadrilateral mesh in a rectangular domain. Such a mesh is commonly used in Finite Element Analysis and can be further employed in single- and two-phase flow simulations. The main advantage of arbitrary quadrilateral meshes over triangular meshes i

    Duration: 8s
  • Efficient Laplacian Smoothing on Quadrilateral Mesh

    This animations show the effect of the Laplacian Smoothing operation on quadrilateral mesh in a rectangular domain. Such a mesh is commonly used in Finite Element Analysis and can be further employed in single- and two-phase flow simulations. The main advantage of arbitrary quadrilateral meshes over triangular meshes i

    Duration: 8s
  • Passive particle transport of 200 particles

    This video shows a 2D passive particle transport of 200 particles in a channel with an obstacle. The motion is only given by the update position differential equation X^n+1 = X^n + v * dt, where n+1 is the future postion, n is the current position and v is the flow velocity, which does not depend on the particle’s moti

    Duration: 28s
  • Bloodstream flow with drug-eluting stents in coronary artery

    The video shows the numerical simulation of bloodstream flow in coronary artery with drug-eluting stents implanted to reduce buildup of fat deposition. The simulation was made using the Finite Element method and an unstructured triangular mesh and high order interpolation. The results reveal an interesting drug diffusi

    Duration: 27s
  • Slug flow in sinusoidal channel

    This is a numerical simulation of slug flow in sinusoidal channel using the finite element method and the moving-mesh/moving-boundary technique found in (https://doi.org/10.1016/j.cma.2020.112820). As can be seen 3 confined drops are flowing thru the corrugated channel and its cross-sectional variation changes the drop

    Duration: 9s
  • Jet stream during conversation (COVID-19/SARS-CoV-2)

    This animation shows the solution of a 2-dimensional flow jet stream during conversation of a human being possible contaminated with COVID-19. This study aims at investigate the persistence of a certain number of droplets with viral load in air.

    Duration: 4s
  • 2d Particle Collisions

    This video shows the collisions of several particles with different sizes in a closed rectangular domain. Momentum is conserved in an isolated system with full elastic shocks between particles with different mass. As can be seen in this model, the heavier particles do not change their velocities too much with collision

    Duration: 40s
  • Rising of air bubble in water-sugar solution (Bhaga and Weber, 1981)

    This movie shows the numerical solution of an initially spherical air bubble in a quiescent water-sugar solution using a moving frame view point where the bubble’s centroid remains fixed in space while fluid flows downward. In this approach, the interface mesh is built as a set of interconnected nodes and finite triang

    Duration: 16s
  • VIV ALE-FE

    VIVALE - Vortex-induced vibration using Arbitrary Lagrangian-Eulerian Finite Element Method for 2D simulation. In this video, the cylinder motion is controlled by a simple analytical function and adaptive mesh refinement is used to control mesh quality near the cylinder.

    Duration: 46s
  • Rotating disk flow

    The plot shows the evolution of the 3 boundary layers with time, according to the transient solution of the Navier-Stokes equations for the Rotating Disk Flow problem (see Schlichting Boundary Layer Theory)

    Duration: 9s
  • Sessile drop

    In this test case, the numerical solution of a sessile drop is compared to the exact solution given by a set of ordinary equations for a 3D axisymmetric drop, both compared during the last 2 seconds of this animation. The test consists in releasing a drop and, due to gravitational force, the drop approaches the wall. I

    Duration: 12s
  • 3D vortex field

    3-dimensional vortex field test case. This particular benchmark tests extensively the remeshing methodology implemented in our CFD code. The test consists in applying a 3d vortex field on a sphere which will be complete distorted in t=0.5T, where T is the total time of the simulation. From t=0.5T to t=T, the vortex fie

    Duration: 7s
  • Single vortex simulation

    In this test case, the remeshing methodology is massively tested while the bubble is subjected to a single vortex field. The tetrahedral background mesh is colored by the magnitude of the vortex field velocity. The red color represents high velocity, while the blue one stands for low intensity. As can be seen, the volu

    Duration: 20s
  • Zalesak's rotating sphere test case

    The Zalesak’s test case is a common benchmark to evaluate the reconstruction of the interface while the Zalesak sphere is rotating. The background flow is imposed with no need of solving the Navier-Stokes equations. As can be seen in the animation and despite the coarse mesh used on this test case, our moving mesh meth

    Duration: 20s
  • Squeezing of 2 bubbles

    Modeling of last stage of two bubble’s coalescence process. The animation shows three different views of the same simulation to illustrate the approaching of two bubbles. Using the 3D ALE-FEM code, we are able to study the physical phenomena that takes place before the unexplored and non-trivial process of bubble coale

    Duration: 15s
  • cross section triangle

    Two-phase flow of a single bubble in a triangular channel. The Navier-Stokes equations are discretized through the Arbitrary Lagrangian-Eulerian framework in which the interface between fluids are accessed sharply by defining a triangular surface embed on the tetrahedral mesh. In such a particular simulation, the confi

    Duration: 15s
  • Rising air bubble in sugar syrup solution

    Gravity-driven flow of an air bubble in sugar-syrup solution. The result was compared to the White and Beardmore flow pattern map (1962) and good agreement was found for the rising velocity of the air bubble and the liquid film thickness.

    Duration: 10s
  • Rising air bubble in sucrose solution

    Gravity-driven flow of an air bubble in sucrose solution. The result was compared to the White and Beardmore flow pattern map (1962) and good agreement was found for the rising velocity of the air bubble and liquid film thickness.

    Duration: 6s
  • Rising air bubble in sucrose solution

    Gravity-driven flow of an air bubble in sucrose solution. The result was compared to the White and Beardmore flow pattern map (1962) and good agreement was found for the rising velocity of the air bubble and liquid film thickness.

    Duration: 10s
  • Two-phase flow evaporation in microchannel

    Heat and Mass transfer of refrigerant R1234ze in square cross-section microchannels with a constant heat flux applied on the bottom of the domain. Red color represent high temperature and blue stands for low temperature.

    Duration: 20s
  • Microchannel two-phase flow of refrigerant R1234ze.

    Two-phase slug flow in square cross-section microchannels. 3D Finite Element simulation was successfully carried out to predict bubble shape, velocity, liquid slug and liquid film thickness in the scope of the CMOSAIC project financed by NanoTera in Switzerland. The liquid and gas phases correspond to the refrigerant R

    Duration: 11s
  • Rising air bubble in glycerol solution

    Gravity-driven flow of an air bubble in sugar-syrup solution. The 3D equations were discretized using the ALE framework and the Finite Element Method. The numerical result was compared to the White and Beardmore flow pattern map (1962) and good agreement was found for the rising velocity. Bubble shape and liquid film t

    Duration: 10s
  • 2D Rising Bubble Heat Transfer

    2D simulation of a rising bubble with heat transfer. The bubble, lighter then the surrounding fluid, rises and moves towards the heat interface (green color) . The non-dimensional numbers used in this simulations were Re = 200, Sc = 1000, We = 10, mu_in = 0.5, mu_out = 1.0, rho_out = 1.0, rho_in = 0.01. On the right ha

    Duration: 17s
  • 2D Heat Transfer Bubble Rising

    Rising of a single bubble immersed in a fluid where the bottom part (red) is heated and has temperature higher then the upper part (blue). The bubble is then release and due to buoyancy effect, it crosses the heat transition line (green color). The heat transfer process takes place into the bubble dynamic and due to th

    Duration: 12s
  • 3D Point Deletion Strategy

    The interface between fluids is represented by a set of points, edges and facets. These facets are triangles which are part of the tetrahedron mesh. Each triangle represents the shared facet of two adjacent tetrahedrons. As can be seen, while the surface movies with respect to the flow, the elements are compressed spoi

    Duration: 8s
  • 3D Point Insertion Strategy

    The interface between fluids is represented by a set of points, edges and facets. These facets are triangles which are part of the tetrahedron mesh. Each triangle represents the shared facet of two adjacent tetrahedrons. As can be seen, while the surface movies with respect to the flow, the elements are stretched spoil

    Duration: 8s
  • 3D Air-Water Flow

    The rising of a single air bubble in a stagnant column of water has been simulated. The 3-dimensional two-phase flow phenomena can be numerically predicted. At the leftmost frame, the interface between fluid is represented by a set of points, edges and triangular facets which are part of the tetrahedron domain mesh. Th

    Duration: 10s
  • 2D Microchannel Coalescence

    Numerical simulation of 2D microchannel two-phase flow. The equations are written in the Arbitrary Lagrangian-Eulerian framework (ALE) through the Finite Element method (FEM), ANJOS et al. (2013). The bubble velocity profile is shown on the top of the figure where the highest horizontal speed is represented by the red

    Duration: 7s
  • 3D Air-Water-Sugar Flow

    Numerical simulation of 3-dimensional two-phase flow is performed to predict the rising of an air bubble in a initially stagnant water-sugar solution. At the leftmost frame, the interface between fluid is represented by a set of points, edges and triangular facets which are part of the tetrahedron domain mesh. The midd

    Duration: 32s
